DM3102 | 2D MEMS Evaluation Kit

MEMS EVALUATION KIT

Maradin DM3100 Evaluation Kit is an easy to use and a straight forward platform for developers and business development personal.

The DM3100 enables the evaluation of Maradin’s laser based projection core components, including: MAR1100 – 2D MEMS scanning mirror, MAR2100 – MEMS drive and control IC and the MAR3100 – GILBOA reference design to incorporate Maradin’s proprietary laser timing algorithm. The DM3100 shortens the development time, enables flexibility and a fast demonstration of laser projection based on Maradin’s technology.

KEY FEATURES AND BENEFITS

  • 2D single mirror– Minimizes optical engine size and increases optical efficiency

  • Combination of electrostatic (H) and electromagnetic (V) actuators – Improves robustness and optimizes performance

  • Wide optical FOV, 45° (H) x 30° (V) – Delivers large image/scan area

  • High-sensitivity, dynamic closed control loops – Maintain stable peak performance even during changes in ambient conditions

  • Static mirror alarm signal – Supports eye safety

  • MEMS controller with standard digital video interface – Simplifies system design and integration

  • Non-hermetic plastic package – Reduces cost

mar1100e MEMS 2D Scanning Mirrors
  • MAR1100

    MEMS 2D LASER SCANNING MIRROR​​​

MAR2100 MIRROR CONTROLLER IC
  • MAR2100 | MIRROR CONTROLLER IC​

    based on 0.18um process for both 1D or 2D, using analog feedback | Generally available

HOW THE LASER SCANNING PROJECTOR WORKS

The MAR1100 is a dual-axis MEMS based scanning mirror targeted for miniature laser projectors and laser steering applications. It is based on industry-leading MEMS technology with novel and precise actuation schemes. The innovative MEMS device combines a fast electro-static actuator and a powerful electro-magnetic actuator, which yields peak performance under varying conditions.

The MAR2100 is a Driver and control IC for Maradin’s MAR1100 dual-axis MEMS based scanning mirror. MAR2100 is targeted for miniature laser projectors and laser steering applications. MAR2100 drives and controls Maradin’s MAR1100 dual axis scanning mirror and generates the timing signals to synchronize the laser module through the Host, also called as Data Manipulator. As MAR1100 scanner has two uncoupled actuators – one for horizontal scan and one for vertical scan, MAR2100 controller IC supports both drivers.

The MAR1100 scanning mirror, combined with the MAR2100 controller IC, from the projection module of the system. A general block diagram of such systems is depicted in the animation below.

Flexibility and Customization

Packaging

Maradin package can be fully adapted to the needs of different systems

  • Plastics, ideal for low cost consumer applications of display and sensing

  • Ceramics, could meet the requirements of the automotive market

Optical coating

Maradin has the ability to adjust the coating of the MEMS to the different wavelengths.

  • Laser Damage Threshold

  • Custom laser wavelength coating using Bragg reflectors

  • More than 97% reflectivity for UV (405nm), Visible (450~700), IR (800~1550) lasers

Connectivity

  • Mardin's MEMS Mirror can work with internal laser or synchronize to external laser

  • MEMS could be Extended from the controller up to 50cm

  • Synchronization of several mirrors together

  • The sensing signals of the MEMS could serve as safety alarms

MAR1100.E Common Applications

  • Automotive

    Automotive grade design, including a special hermetic packaging with advanced heat dissipation. High stability for vibrations and temperature changes

  • AR/VR Display

    A low power design, with a non-uniform pixel distribution to form a proprietary foveated view. Extremely compact volume and packages options

  • Pico Projector

    A flexible Picture Generating Unit (PGU) design with a verity of laser wavelengths and optical coating options

MAR1100.E – MEMS SCANNING MIRROR SPEC:

Item Specification
Optical angle (H x V)
Typ.: 45x20 Deg.Max: 45x30 Deg.
Resolution (HxV)
Typ.: 1280x480 pixelsMax: 1280x600 pixels
Pixel position error
+/- 1/5 pixel
Resonance frequency (H)
10,250 Hz
Resonance frequency (V)
1800 Hz
Effective mirror size (H)
1 mm
Effective mirror size (V)
1.1 mm
MEMS Scanning Module dimensions (L x W x H)
Typ.: 12×6.5×5.9 mmSmall: 10×5.5×4.6 mm
MEMS Scanning module power consumption
70 mW (rms)
Package
Typ.: Plastic, Non-HermeticCustom: Ceramic, Hermetic
Item Specification
Throw Ratio
1.2
Incident angle (H)
0 Deg.
Incident angle (V)
15 – 22 Deg.
Mirror reflectance
Typ.: 90-93% (Aluminium coating)Max: 99.5% (High Reflective Coating)
Overall reflectance
85% (Mirror & Optical window)
Wavelength range for reflection
Typ.: 440 -700 mmCustom: Any wavelength upon request
laser max spot size
0.7 mm
MARADIN'S TECHNOLOGY INCLUDES THE FOLLOWING KEY ELEMENTS:
  • Fast electrostatic (ES) actuator with minimal power consumption. The ES actuator operates in the self-resonance frequency of the mirror and is ideal for high scan frequencies (tens of KHz).

  • Strong and accurate electromagnetic (EM) actuator. The EM actuator is ideal for point-to-point or slow scan patterns.

  • Capacitive sensors measure the mirror angular position with very high precision and fast response.

  • Sophisticated control circuitry and algorithms perform continuous, close control of the mirror motion, ensuring the utmost accuracy, repeatability and temperature stability.
